Modern MTB Design

Tapered fork steerer tubes*, quality components like a 1x drivetrain* with a clutch-equipped rear derailleur, thru-axle hubs*, internal cable routing (including dropper post compatibility), and integrated chainstay protection provide everything you need to build confidence and skills on the trails. (*select models)

Off-Road Control

The new geometry is optimized for confident trail riding, with two wheel size options (27.5- or 29-inch) based on frame size. It’s also designed to match front suspension travel with either an 80mm or 100mm fork. All models have clearance for high-volume tires (up to 2.4 inches) for traction and grip on technical terrain.

Light and Durable

The all-new ALUXX aluminum frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.

• Frame
  ALUXX-grade aluminum, disc
• Fork
  SR Suntour XCE, QR, steel steerer 27.5" XS: 80mm, S: 80mm 29" S: 100mm, M: 100mm, L: 100mm
• Shock
  N/A
• Handlebar
  Giant Connect Trail, 31.8mm 27.5" XS: 690mm, S: 690mm 29" S: 750mm, M: 750mm, L: 750mm
• Grips
  Giant Sole-O
• Stem
  Giant Sport, 7-degree 27.5" XS: 40mm, S: 40mm 29" S: 40mm, M: 50mm, L: 50
• Seatpost
  Giant Sport, 30.9mm 27.5" XS:100x350mm, S: 100x350mm 29" S: 100x350mm, M:100x375mm, L : 100x375mm
• Saddle
  Contact Ergo
• Pedals
  MTB caged
• Shifters
  Microshift, Acolyte 1x8, SL-M6180-R
• Front Derailleur
  N/A
• Rear Derailleur
  Microshift, Acolyte 1x8, RD-M5185M with clutch
• Brakes
  TKB-172, mechanical [F]160mm, [R]160mm rotors
• Brake Levers
  RS360A, mechanical
• Cassette
  Microshift, Acolyte, CS-H083, 12-46
• Chain
  KMC 8.3
• Crankset
  ProWheel C10Y-NW 52.5mm chainline 32t (27.5") & 30t (29") 27.5" XS: 165mm, S: 165mm 29" S: 170mm, M: 170mm, L: 170mm
• Bottom Bracket
  cartridge
• Rims
  27.5": Giant GX03V 27.5", alloy, double wall, 21mm inner width 29": Giant GX03V 29", alloy, double wall, 21mm inner width
• Hubs
  alloy, sealed bearing
• Spokes
  stainless, 14g
• Tires
  Maxxis Ikon 27.5x2.4" or 29x2.4", 60tpi wire bead
• Extras
  2.4" max tire size, max chainring 32T
• Weight
  13.91 kg (30 lbs 11 oz) - Size (L)
